Opis
PSR PRO98 HP Rating 2550
- Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion - 13 Blade G-Aero billet compressor wheel 98mm inducer produces up to 2550 hp
- 9 Blade G-Aero Inconel 713c turbine wheel with more turbine flow
- Fin cooled aluminum center housing, lighter weight
- Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
- Installation Hardware: 4?? flange kit for Comp. Outlet, T6 Gasket/3.5?? flange kit for Turb. Inlet,?5?? flange kit for Turb. Outlet and oil Drain Fitting kit are included by default
- Oil Feed Fitting(-4AN ? 1.65mm (0.065??) Orifice) included
Compressor Housing: W/O Compressor Housing
Turbine Housing: W/O Turbine Housing
- Compressor Wheel: 98.4*133.5*142.4mm
- Turbine Wheel: 118*112mm
- Compressor Inlet: 6 Hose
- Compressor Outlet: 4 V-band
- Compressor Housing A/R: 0.96
- Turbine Inlet: 3.5 V-Band (DV Housings) or T6 Open
- Turbine Outlet: 5 V-Band
- Turbine Housing A/R: 1.09/1.25/1.41
- Oil Feed: See graph below(OIL INLET) (an oil restrictor with ~1mm orifice is highly recommended)
- Oil Drain: See graph below(OIL OUTLET)
